The ILab 650 is the latest and most sophisticated model to be added to the ILab family. With up to 100 active tests on board including general chemistries, specific proteins, TDM and DAT; it offers the flexibility to consolidate workstations in medium sized laboratories, and due to its open nature, consolidation of speciality tests in the larger laboratory.



The ILab650 can analyse 400 photometric tests/hour, and with an optional ISE module the throughput increases to give a total of up to 800 tests/hour. The analyser, which has a small footprint and an elegant industrial design, is controlled by an external PC running under Windows XP. The easy to use software offers a full audit trail of patient data. This links individual results directly to calibration and QC information, with material lot numbers, analysed prior to the patient result.



Productivity

·    Samples easily accessible

·    Continuous sample loading without affecting work in progress

·    Throughput of 400 photometric and up to 400 ISE tests/hour.

·    Small footprint W 980 mm, D 400 mm, H 1180 mm

·    Floor standing system



Integration into the laboratory

·    Samples easily accessible

·    Continuous sample loading without affecting work in progress

·    Throughput of 400 photometric and up to 400 ISE tests/hour.

·    Small footprint W 980 mm, D 400 mm, H 1180 mm

·    Floor standing system



Sample management

·    Test menu and patient demographics presented on one screen

·    75-position sample tray allowing the use of any type of primary tube without the need for adapters, and cups.

·    Bar code sample identification at the point of aspiration

·    Continuous loading capability

·    Bi-directional interface with the Laboratory Information system with Host Query or batch download.

·    Automatic pre-dilution of samples as required



Reagent management

·    96 position refrigerated reagent tray

·    Tray accepts a wide range of containers from 10 mL to 100 mL

·    Bar code identification (including lot number and expiry date)

·    Real time update of the remaining tests on board

·    Reagent low warning, configurable by test

·    Reagent short warning

·    Lot expiry warning

·    On board life expiry warning

·    Re-calibration warning

·    Reagent blank automatically run at start up

·    Reagent blank automatically run at bottle change

(in the event of two or more bottles of the same reagent being on board)



ISE module

·    Integrated ISE module for the determination of Na, K, and Cl on serum, plasma and urine.

·    Maintenance-free electrodes

·    Continuous automatic calibration ensuring that the system is always ready for analysis

·    Results available in real time

·    Less than one minute for the three electrolytes (sodium, potassium and chloride)

·    One minute for photometric tests such as glucose



Opennes and flexibility

·    All 100 applications are totally open allowing implementation of non-IL tests

·    All parameters for each test are presented on a single page

·    Up to 4 reagents per test

·    Multi point calibration curves with up to 6 calibrators

·    Refrigerated reagents

·    81 reusable Pyrex cuvettes



Result availability

·    Less than three minutes for Urea and Glucose

·    Five minutes for the majority of enzyme tests

·    Reaction curves can be both displayed and printed

·    User configurable automatic re-run

·    User configurable reflex tests



Data integrity

·    Reagents specifically developed and CE marked for the ILab system

·    Integrated Quality control program

·    Test-selectable Westgard Rules

·    Real Time validation of QC data

·    Complete statistics program

·    Levy-Jennings and Twin (Youden) Plots



Safety and convenience

·    Access to both samples and reagents is from the front of the analyser

·    Samples and reagents can be accessed and changed during analysis



Economy

·    No dedicated consumables

·    Easy handling of infrequent tests

·    Customized reagent kit configurations allow running of special tests with minimal reagent wastage

·    Open and flexible system



Test menu

·    Routine Clinical Chemistry

·    Electrolytes

·    Specific Proteins

·    Therapeutic drugs

·    Drugs of abuse

·    Ready to use liquid reagents

·    Calibrators and Quality Control Materials for all applications
